TP-Link Archer GX90 OneMesh/EasyMesh WiFi6 router (AX6600,2,4GHz/5GHz/5GHz,1x2,5GbELAN/WAN,1xGbELAN/WAN,3xGbELAN,2xUSB)
Popis a parametry
TP-Link Archer GX90 OneMesh/EasyMesh WiFi6 router (AX6600,2,4GHz/5GHz/5GHz,1x2,5GbELAN/WAN,1xGbELAN/WAN,3xGbELAN,2xUSB)
TP-Link Archer GX90
Třípásmový herní Wi-Fi 6 router AX6600
- Herní pásmo – třípásmové provedení poskytuje 4,8Gbit/s herní pásmo vyhrazené pro vaše herní servery a umožňuje ničím nerušené hraní.
- Herní akcelerátor – detekuje a optimalizuje herní streamy, abyste mohli zůstat ponoření v herním světě.
- Herní statistiky – latence v reálném čase, doba hraní a vyhrazené síťové prostředky přehledně ve vyladěném uživatelském rozhraní.
- Herní ochrana – chraňte své účty a dokumenty se systémem zabezpečení Homecare™.
- Široké pokrytí – 8 antén, technologie Beamforming, výkonný modul FEM a 4T4R zajišťují pokrytí Wi-Fi signálem až pro 5pokojové domácnosti.
- Kabelové připojení 2,5 Gbit/s – odhalte potenciál sítě s šířkou pásma příští generace díky portu 2,5 Gbit/s WAN/LAN.
- Výkonný procesor – 1,5GHz čtyřjádrový procesor je zárukou, že síť vždy poběží na plný výkon.
- Snadné nastavení – s propracovanou aplikací Tether je nastavení otázkou několika málo minut.
Stránky produktu: https://www.tp-link.com/cz/home-networking/wifi-router/archer-gx90/
Technické specifikace
| WIRELESS | |
| Standards | Wi-Fi 6 IEEE 802.11ax/ac/n/a 5 GHz IEEE 802.11ax/n/b/g 2.4 GHz |
| WiFi Speeds | AX6600 5 GHz: 4804 Mbps (802.11ax, HE160) 5 GHz: 1201 Mbps (802.11ax) 2.4 GHz: 574 Mbps (802.11ax) |
| WiFi Range | 4 Bedroom Houses 8× Detachable High-Performance Antennas Multiple antennas form a signal-boosting array to cover more directions and large areas Beamforming Concentrates wireless signal strength towards clients to expand WiFi range High-Power FEM Improves transmission power to strengthen signal coverage 4T4R Multiple streams in the same band strengthen the fault tolerance in transmission |
| WiFi Capacity | Very High Tri-Band Allocate devices to different bands for optimal performance 4×4 MU-MIMO Simultaneously communicates with multiple MU-MIMO clients OFDMA Simultaneously communicates with multiple Wi-Fi 6 clients Airtime Fairness Improves network efficiency by limiting excessive occupation DFS Access an extra band to reduce congestion 8 Streams Connect your devices to more bandwidth |
| Working Modes | Router Mode Access Point Mode |
| HARDWARE | |
| Processor | 1.5 GHz Quad-Core CPU |
| Ethernet Ports | 1× 2.5 Gbps WAN/LAN Port 1× Gigabit WAN/LAN Port 3× Gigabit LAN Ports |
| USB Support | 1× USB 3.0 Port 1× USB 2.0 Port Supported Partition Formats: NTFS, exFAT, HFS+, FAT32 Supported Functions: Apple Time Machine FTP Server Media Server Samba Server |
| Buttons | Wi-Fi On/Off Button Power On/Off Button LED On/Off Button WPS Button Reset Button |
| Power | 12 V = 5 A |
| SECURITY | |
| WiFi Encryption | WPA WPA2 WPA3 WPA/WPA2-Enterprise (802.1x) |
| Network Security | SPI Firewall Access Control IP & MAC Binding Application Layer Gateway HomeCare™ Antivirus Malicious Site Checker Port Intrusion Prevention Infected Device Isolation Notification and Log |
| Guest Network | 2× 5 GHz Guest Network 1× 2.4 GHz Guest Network |
| VPN Server | OpenVPN PPTP |
| SOFTWARE | |
| Protocols | IPv4 IPv6 |
| Game Center | Game Accelerator Detects and optimizes gaming streams to keep latency as low as possible Game Statistics Check real-time latency, system utilization, and game duration on a redesigned dashboard to tweak every detail Game Protector Keep your accounts and system safe with HomeCare™ antivirus protection |
| Service Kits | HomeCare™ Learn More> |
| OneMesh™ | OneMesh™ Supported Without replacing your existing devices or buying a whole new WiFi ecosystem, OneMesh™ helps you create a more flexible network that covers your entire home with TP-Link OneMesh™ products. Learn More> All OneMesh Products> |
| Parental Controls | HomeCare™ Parental Controls Custom Profiles Content Filtering App Block URL Filtering Time Limit Time Schedule (Bedtime) Log Insight |
| WAN Types | Dynamic IP Static IP PPPoE PPTP L2TP |
| Quality of Service | Game Accelerator QoS. QoS by Device HomeCare™ QoS QoS by Application |
| Cloud Service | Auto Firmware Upgrade OTA Firmware Upgrade TP-Link ID DDNS |
| NAT Forwarding | Port Forwarding Port Triggering DMZ UPnP |
| IPTV | IGMP Proxy IGMP Snooping Bridge Tag VLAN |
| DHCP | Address Reservation DHCP Client List Server |
| DDNS | TP-Link NO-IP DynDNS |
| Management | Tether App Webpage Check Web Emulator> |
| PHYSICAL | |
| Dimensions (W×D×H) | 8.3 × 8.3 × 2.0 in (212 × 212 × 51.8 mm) |
| Package Contents | Wi-Fi Router Archer GX90 Power Adapter RJ45 Ethernet Cable Quick Installation Guide |
| OTHER | |
| System Requirements | Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser Cable or DSL Modem (if needed) Subscription with an internet service provider (for internet access) |
| Certifications | FCC, CE, RoHS |
| Environment | Operating Temperature: 0°C~40°C (32°F ~104°F) Storage Temperature: -40°C~70°C (-40°F ~158°F) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
| TEST DATA | |
| WiFi Transmission Power | CE: <20dBm(2.4GHz) <23dBm(5.15GHz~5.35GHz) <30dBm(5.47GHz~5.725GHz) FCC: <30dBm(2.4GHz & 5.15GHz~5.25GHz & 5.725GHz~5.825GHz) <24dBm(5.25GHz-5.35GHz & 5.47GHz-5.725 GHz) |
| WiFi Reception Sensitivity | 5 GHz-1: 11a 6Mbps:-93dBm, 11a 54Mbps:-76dBm 11ac VHT20 MCS0:-92dBm, 11ac VHT20 MCS8:-69dBm 11ac VHT40 MCS0:-90dBm, 11ac VHT40 MCS9:-65dBm 11ac VHT80 MCS0:-87dBm, 11ac VHT80 MCS9:-62dBm 11ax HE20 MCS0:-93dBm,11ax HE20 MCS11:-62dBm 11ax HE40 MCS0:-90dBm,11ax HE40 MCS11:-59dBm 11ax HE80 MCS0:-87dBm,11ax HE80 MCS11:-56dBm 5 GHz-2 (Gaming Band): 11a 6Mbps:-96dBm, 11a 54Mbps:-77dBm 11ac VHT20 MCS0:-95dBm, 11ac VHT20 MCS11:-64dBm 11ac VHT40 MCS0:-93dBm, 11ac VHT40 MCS11:-62dBm 11ac VHT80 MCS0:-90dBm, 11ac VHT80 MCS11:-59dBm 11ac VHT160 MCS0:-84dBm, 11ac VHT160 MCS11:-53dBm 11ax HE20 MCS0:-93dBm,11ax HE20 MCS11:-62dBm 11ax HE40 MCS0:-90dBm,11ax HE40 MCS11:-59dBm 11ax HE80 MCS0:-87dBm,11ax HE80 MCS11:-57dBm 11ax HE160 MCS0:-84dBm,11ax HE160 MCS11:-54dBm 2.4 GHz: 11g 6Mbps:-96dBm, 11g 54Mbps:-77dBm 11n HT20 MCS0:-95dBm, 11n HT20 MCS7:-76dBm 11n HT40 MCS0:-93dBm, 11n HT40 MCS7:-73dBm 11ac VHT20 MCS0:-95dBm, 11ac VHT20 MCS8:-73dBm 11ac VHT40 MCS0:-92dBm, 11ac VHT40 MCS9:-68dBm 11ax HE20 MCS0:-95dBm,11ax HE20 MCS11:-64dBm 11ax HE40 MCS0:-95dBm,11ax HE40 MCS11:-62dBm |
.
ParametryPorovnání
Typ aktivního prvku
AP (Access Point)
Frekvenční pásmo (GHz)
2,4
Připojení externí antény
Ne
Podporované standardy
802.11n
USB port
Ano
Další vlastnosti
Rodičovská kontrola
Slot na SIM kartu
Ne
Počet portů LAN
5
Použití
Vnitřní
Zabezpečení
WPS
Typ antény
Vestavěná
Počet portů LAN
5
