CHIEFTEC zdroj iARENA, GPC-600S, 600W, 120mm fan, PFC, 80%, bulk
Popis a parametry
CHIEFTEC zdroj iARENA, GPC-600S, 600W, 120mm fan, PFC, 80%, bulk
Performance | |
AC Input: | 230V / 6,3A |
Frequency: | 50 Hz |
+5V: | 22A |
+3,3V: | 22A |
+5V & +3,3V combined: | 120W |
+12V 1: | 45A/540W |
+12V 2: | N/A |
+12V 1 & +12V 2 combined: | N/A |
+12V 3: | N/A |
+12V 4: | N/A |
+12V 3 & +12V 4 combined: | N/A |
P.F.: | >0,9 |
-12V: | 0,3A / 3,6W |
+5VSB: | 2,5A / 12,5W |
Maximum Load: | 600W |
Connectors | |
Native cable: | |
24PIN: | |
===450mm===[24PIN] | |
SATA/Molex: | |
===350mm===[SATA]===150mm===[SATA]===150mm===[SATA]===150mm===[Molex] | |
SATA/Molex: | |
===350mm===[SATA]===150mm===[SATA]===150mm===[SATA]===150mm===[Molex] | |
6+2 PCIe: | |
===450mm===[PCIe]===150mm===[PCIe] | |
8PIN EPS (4+4): | |
===500mm===[4PIN EPS]===150mm===[4PIN EPS] |
.
ParametryPorovnání
Formát zdroje
ATX
Konektory
FDD
Konektory pro základní desku
EPS 8-pin
Efektivita zdroje
80 Plus
Modulární kabeláž
Ne
Výkon zdroje (W)
600
CHIEFTEC zdroj iARENA, GPC-600S, 600W, 120mm fan, PFC, 80%, bulk
